Double Spindle CNC Router

Name: Double Spindle CNC Router
Brand: K TECH CNC
Price: 490000 INR
Availability: InStock

Price 490000 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Double Spindle CNC Router Specification

Product Type
Double Spindle CNC Router

General Use
Wood/Plastic engraving, cutting, milling, drilling

Material
Steel (body), Aluminium (table), ABS (cover)

Type
CNC Router

Capacity
Two spindle simultaneous machining

Weight (kg)
Approx. 1350 kg

Computerized
Yes

Automatic
Fully Automatic

PLC Control
Available

Bar Feeder
Not Equipped

Power Source
Electric

Power Consumption
3.5 kW

Rigidity
High

Voltage
220V/380V (Optional)

Motor
Stepper Motor / Servo Motor (Customizable)

Table Size
1300mm x 2500mm

Spindle Speed
0-24000 RPM

Axial Choice
X, Y, Z Axis

Dimension (L*W*H)
3250mm x 2200mm x 1700mm

Feature
Dual independent spindles, High speed cutting, Precision machining

Color
Blue & White

Safety System
Emergency Stop Button, Overload Protection

Operating Temperature
0C 40C

Drive System
Helical Rack & Pinion / Ball Screw

Lubrication System
Automatic

Dust Collection Port
Yes

Ambient Humidity
30% 75%

Cooling System
Water-cooled Spindle

Transmission Accuracy
0.02 mm

Supported File Format
G-code, DXF, HPGL

Communication Interface
USB/Parallel Port

Max Workpiece Height
200 mm

Controller System
DSP / Mach3 (Optional)

Repeat Positioning Accuracy
0.05 mm

Spindle Power
3.5 kW each

Software Compatibility
ArtCAM, TYPE3, UG, CorelDraw

Double Spindle CNC Router Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
Unit

Delivery Time
12 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Main Domestic Market
All India

About Double Spindle CNC Router

This ergonomically designed Double Spindle CNC Router has wide application in furniture making and sheet metal processing industries. It consists of necessary components like advanced control system and driver of renowned brands. This CNC equipment requires 800w power and its weight is 1000 kg. We are a growth oriented manufacturer and supplier of Double Spindle CNC Router.

Product Details:

Minimum Order Quantity	1 Piece
Max height for material	200 mm
Power Consumption	800 w
Weight	1000 Kg
Spindle Speed (rpm/min)	6000-24000 rpm
Work Table Area	1600 X 3010 mm
Max width for Material	1600 mm

Dual Spindle Advantage

Designed for high-volume operations, the routers twin independent spindles allow for simultaneous machining, effectively reducing production time and maximizing throughput. Each spindle operates with 3.5 kW power, supported by a water-cooling system for extended reliability during long manufacturing cycles.

Precision and Control

The machine is built with helical rack & pinion or ball screw drives, ensuring precise movement along the X, Y, and Z axes with repeat positioning accuracy of 0.05 mm. The DSP/Mach3 controller system provides real-time command flexibility, making it suitable for intricate and large-scale projects.

Robust Safety and Automation Features

The CNC router prioritizes operator safety with an emergency stop button and overload protection. Automatic lubrication and dust collection ports maintain hassle-free and clean operation, reducing maintenance while enhancing component lifespan for prolonged uninterrupted use.

FAQs of Double Spindle CNC Router:

Q: How does the double spindle feature increase production efficiency?

A: The dual independent spindles enable the CNC router to perform two machining operations simultaneously, effectively doubling output and minimizing processing time for high-volume production environments.

Q: What types of materials can this router process?

A: This CNC router is optimized for wood and plastic materials, offering precise engraving, cutting, milling, and drilling capabilities on both with its high-speed spindles and robust construction.

Q: When is the automatic lubrication system activated during operation?

A: The built-in automatic lubrication system functions at scheduled intervals while the machine is running, ensuring all moving parts remain optimally lubricated, which lowers maintenance efforts and extends the machines lifespan.

Q: Where is the dust collection port located on the router, and how is it used?

A: The dust collection port is strategically positioned near the machining area to capture debris generated during cutting and engraving. Connecting an external dust collector helps maintain a clean workspace and improves air quality.

Q: What software is compatible with this CNC router for file design and transfer?

A: The router supports popular software such as ArtCAM, TYPE3, UG, and CorelDraw, as well as file formats like G-code, DXF, and HPGL, enabling seamless integration into established production workflows.

Q: How does the emergency stop button and overload protection enhance safety?

A: The emergency stop button provides immediate shutdown capability, while overload protection automatically disconnects power in case of excessive load or fault, thereby safeguarding both the operator and the equipment during operation.

Q: What are the benefits of using a water-cooled spindle versus air-cooled alternatives?

A: Water-cooled spindles maintain stable temperatures even during extended high-speed cutting, offering quieter operation and longer spindle life compared to air-cooled systems, which is ideal for continuous manufacturing.
